WANDLA + HYPSOS

WANDLA can be upgraded with HYPSOS Hybrid Power System using our proprietary Ferrum Power Link (FPL) connection, making both units perform to their highest levels. While WANDLA performs very good right out of the box, it is made to excel above and beyond when used together with HYPSOS.

Using the FPL connection means HYPSOS can measure far deeper inside WANDLA than it can with any other product. Not only does HYPSOS work better in this combination, WANDLA will also perform even better than it normally does. The truly balanced design of the preamplifier stage coupled with the discrete IC power amplifier technology in combination with the implementation of highly selected components is elevated to a level of its own.

Previous slide
Next slide

WANDLA can be upgraded with HYPSOS Hybrid Power System using our proprietary Ferrum Power Link (FPL) connection, making both units perform to their highest levels. While WANDLA performs very good right out of the box, it is made to excel above and beyond when used together with HYPSOS. Using the FPL connection means HYPSOS can measure far deeper inside WANDLA than it can with any other product. Not only does HYPSOS work better in this combination, WANDLA will also perform even better than it normally does. The truly balanced design of the preamplifier stage coupled with the discrete IC power amplifier technology in combination with the implementation of highly selected components is elevated to a level of its own.

Our proprietary Ferrum Power Link (FPL) cable is key in making the marriage of WANDLA with HYPSOS a happy one. Two wires delivering the power and two wires providing the feedback to ensure flat voltage at every moment. This eliminates the harmful effects of the cable's resistance effectively improving transient response. The current delivery speed at the powered device's input is significantly improved.

To get the most out the combination of WANDLA and HYPSOS you need to connect them with our proprietary FPL DC power cable. The cable is optionally available at your preferred dealer or in our webshop.

Price

3.990

EUR/USD

Order now for delivery after 8th of February 2024

Operation: Fully balanced, proprietary IC power amp
DAC chip:  ESS Sabre ES9038PRO
DAC resolution:  768k/32bit, DSD 256
Digital inputs:– AES/EBU (up to 196kHz/24bit, DoP 64)
  Optical S/PDIF (up t/24bit)
  – Coaxial S/PDIF (up to 192kHz/24bit, DoP 64)
  – USB-C (up to 768kHz/32bit, DSD 256)
  – ARC (up to 192kHz/24bit), TV input with CEC
  – I2S (up to 768kHz/32bit, DSD 256), PS Audio® compatible
MQA®:  decoder and renderer (on all digital inputs)
Analog inputs: RCA
Analog input Vmax:9,5V RMS (2 – 3,5V RMS recommended)
Analogue input imp:47kΩ
Line outputs: balanced XLR; unbalanced RCA
Volume control: analogue with bypass option / digital for DAC operation only
Output level: @0dBFS, 1kHz sine 9,3V RMS balanced, 4,65V RMS unbalanced
Frequency response: 10Hz – 200kHz +/- 0,1dB
analog inputs
DAC THD:  -121dB (0,00009%); THD+N: -115dB (unweighted)
Analog input THD: -123dB @ 2V RMS output level
Dyn. range analog: 127dB (A-weighted)
Dyn. range digital: 127dB (A-weighted)
Crosstalk:  -120dB for 1kHz, better than -100dB for 20Hz -20kHz




Output impedance: 22Ω unbalanced
Output impedance: 44Ω balanced
Power consumption: 10W idle / 15W max
Power inputs: 5,5/2,5 mm DC connector centre positive
proprietary FPL 4-pin DC connector (FPL)
22-30VDC
Power adapter: 100-240 VAC to 24VDC
Dimensions: 21,7 x 20,6 x 5 cm
(WxDxH) 8.6 x 8.1 x 2.0 inch
Weight: 1,8 kg / 3,97 lbs
